SPECIFICATION
| Dimension | 2230*990*450/720mm |
| Patient touching surface | 90*196cm |
| Top Coat: | Electrostatic Powder coating |
| Bed Frame | Cold-Rolled Steel Tube |
| Bed Base: | may X-ray |
| Maximum safe load | 250kg |
| Nurse Controller at bed end board (key-press)— | 1 unit |
| Rail Controller (key-press) | 4 units |
| Imported Linak Electrical Motor | 4 units |
| Angle Scale | 2 units |
| Manual CPR Handle | 1 unit |
| Drainage Hook | 2 units |
| IV. Pole with 4 hooks | 1 unit |
| Diameter 125mm Central Silent Castors | 4 units |
| Detachable ABS Head and Foot Board | 1 pair |
| ABS Side Rail Move with Bed Base Simultaneously | 2 pairs |
| Waterproof | ventilative mattress (optional) |
FUNCTION
1. Height adjustment (450mm-720mm)
2. Angle of backrest's upward 0°- 75°
3. Angle of legrest’s upward 0°- 45°
4. Trendelenburg/Anti-trendelenburg ±10°
5. Auto contour function:
Allows back board and leg board to adjust simultaneously into a chair position
6. Emergency stop function:The bed can be stopped
at all times and positions for one button
