SPECIFICATION
| DETECTOR | Outside caliper rotary detector. (Patent technology ) |
| Controls | Drop counting and adjusting the delivery rate automatically |
| Pump Type | Peristaltic finger |
| Accuracy | ≤25drop/min:±2%, >25drop/min:±3% (With the drop counting control mode) ±5% (With the rate control mode after the correct calibration) |
| Delivery Rate Range | 1～400drop/min(1drop/min step)1.0ml/h～1200ml/h (1.0ml/h～99.9ml/h, 0.1ml/h step; >99.9ml/h, 1ml/h step) |
| Delivery Time Range | 1min～1999min (1 min step) |
| DELIVERY | 1.0ml/h～1200ml/h）（1.0ml/h～99.9ml/h, 0.1ml/h step;<99.9ml/h, 1ml/h step） |
| RATE RANGE | 1～400drop/min（1drop/min step) |
| Volume Limit Range | 0～9999ml (1 ml step) |
| RATE RANGE | 1～400drop/min（1drop/min step) |
| Total Volume Range | 1～9999ml (1 ml step) |
| KVO Rate | When the delivery rate≤10ml/h, KVO is 1 ml/h. Otherwise KVO is 3ml/h |
| Alarms | Air-in-line, Infusion complete when limited volume has been set, Empty container, Occlusion, Door is open, waitting time Over, No drop been detected, Operational errors, Low battery, other device failures |
| BOLUS Bolus rate: | 10~1200ml/hr Bolus volume:Maximum of 100ml |
| Power Supply AC power supply: | AC 100 to 240V±10%，50/60Hz Internal LI Battery: 11.1V, 2000mAh. 8 Hours of continous operation on a new fully charged battery with the rate of 20 drops/min |
| SHOCK PROTECTION | Class I, Type CF |
| DIMENSION & WEIGHT | 130mm×200mm×230mm,2.0kg |
CHARACTERISTICS
Compatible with IV sets of any Brand with high accuracy Automatical calibration for IV sets of any Brand
Three working modes: Drop counting control,Rate control and time control mode
8 Hours internal battery life in high capacity
Has a unique color LCD and an internal battery with a high capability Swith between ml/h and drops/min freely
Three levels of alarm volume: high, medium and low
Three levels of Occlusion pressure: high, medium and low
KVO function: When finish the total volume of an infusion, the pump will alarm and enter KVO state
